40ft High Cube Storage Cargo Container (ISO Standard)

Global Industrial & Intermodal Grade Procurement Specification

Executive Summary & Product Overview

Engineered with 305 mm (12 inches) of additional vertical clearance over standard dry vans, the 40ft High Cube Storage Cargo Container maximizes volumetric capacity for tall, bulky, or high-volume freight and industrial inventory. Built to rigorous ISO international standards, the structure utilizes corrosion-resistant Corten-A weathering steel and a marine-grade laminated timber floor rated for intense, repetitive forklift traffic.

Technical Specifications Matrix

Parameter	Specification	Compliance / Standard
External Dimensions (L x W x H)	12,192 mm x 2,438 mm x 2,896 mm (40' x 8' x 9'6")	ISO 668
Internal Dimensions (L x W x H)	12,032 mm x 2,352 mm x 2,698 mm	ISO 1496-1
Door Opening (W x H)	2,340 mm x 2,585 mm	ISO Tolerances
Cubic Capacity	76.4 m3 (2,698 cu.ft)	Measured
Tare Weight	3,900 kg (+/- 2%)	Weighing Bridge Verified
Max Gross Weight (Rating)	32,500 kg	CSC / ISO 1496-1
Max Payload	28,600 kg	Calculated
Floor Load Capacity	7,260 kg per axle (Tested with 30 x 30 cm fork truck wheels)	ISO 1496-1

Product Selection Guide: Standard vs. High Cube

Selecting the correct container geometry prevents transport bottlenecks and optimizes container utilization ratios across your supply chain:

40ft Standard Dry Van (8'6" Height): Selected for high-density, heavy dead-weight cargo where weight limits (30,480 kg max gross) are reached before volumetric capacity.

40ft High Cube Container (9'6" Height): Selected for low-density, voluminous freight, palletized goods exceeding standard door heights, or industrial storage requiring overhead gantry clearance or tiered racking installations.

Application & Deployment Assessment

Deploying units across diverse industrial operating environments requires matching material and structural thresholds to job-site demands:

Intermodal Freight Transport: Fully certified with a valid CSC (Convention for Safe Containers) safety approval plate for multi-modal rail, road, and ocean transit up to 9-high stacking.

On-Site Industrial Storage: Deployed at manufacturing plants, mining sites, and energy facilities for secure, weather-tight tool and spare parts warehousing. Standard units feature four louvered vents preventing condensation buildup.

Modular Conversion Projects: Serves as the primary structural shell for specialized mobile workshops, generator enclosures, and site offices due to uniform wall thickness and predictable corner-casting load paths.

Materials, Manufacturing & Quality Control

Structural Materials
Framing & Corrugation: JIS G3125 SPA-H (Corten-A) weathering steel. The alloy composition (copper, chromium, nickel) forms a stable rust-inhibiting patina, arresting internal corrosion progression even under marine salt-spray exposure.

Roof Panels: 2.0 mm thick pressed Corten-A steel panels welded via automated CO2 gas-shielded arc welding.

Flooring: 28 mm thick Apitong or Keruing marine-grade hardwood plywood, treated with industrial fungicides, secured to crossmembers with countersunk M8 self-tapping screws.

Manufacturing & Production Process
Shot Blasting: Raw steel plates and structural profiles undergo automated centrifugal shot blasting to SA 2.5 bare metal finish to remove mill scale and impurities prior to fabrication.

Welding Automation: Main structural corner posts and side wall corrugations utilize robotic MIG/MAG welding stations, ensuring uniform weld penetration depth and eliminating porosity defects.

Anti-Corrosion Surface Treatment:

Shop primer application immediately post-blast.
Zinc-rich epoxy primer layer (40 um dry film thickness).
Intermediate high-build epoxy coat (80 um).
Polyurethane (PU) topcoat (40 um), total dry film thickness >= 160 um (conforming to ISO 12944 C5-M).

Testing & Verification
Watertightness Test: Every completed container undergoes a high-pressure rotary water nozzle test (100 kPa water pressure at a distance of 1.5 m) to verify zero seal leakage around door gaskets and roof seams.

Dimensional & Squareness Inspection: Laser-guided coordinate measuring ensures diagonal tolerances remain within +/- 2.0 mm across corner castings.

Lifting & Stacking Test: Prototype testing verifies corner-casting tensile and compressive load limits up to 86,400 kg shear force per ISO 1496 standards.

Supplier Evaluation & Compliance Matrix

Procurement teams assessing factory capability can evaluate suppliers against the following operational benchmarks:

Factory Audit Credentials: ISO 9001 (Quality Management), ISO 14001 (Environmental Management), and ISO 45001 certifications.

Classification Society Approvals: Factory production lines certified by major maritime classification societies including ABS (American Bureau of Shipping), BV (Bureau Veritas), LR (Lloyd's Register), and DNV.

Traceability: Heat number stamping on primary corner castings and steel plates linked directly to mill test certificates (MTCs).

Procurement Decision Workflow

Specification Confirmation: Verify internal clearance requirements, CSC plating validity period, and color codes (RAL standards).

Logistics & Delivery Mode: Choose between One-Way Leased/Shipped (loaded with third-party cargo to reduce positioning freight costs) or Dead Freight Bulk Delivery (stacked up to 8 units on cellular container ships).

Inspection Protocol: Independent third-party inspection (e.g., SGS, Intertek, or Bureau Veritas) conducted prior to ex-factory release.

Documentation Handover: Issuance of Bill of Lading, Manufacturer Certificate of Conformity, CSC Safety Approval Certificate, and individual container serial number register.

Request a Quotation / Inquiry

To initiate a commercial proposal or technical submittal review, provide the following parameters:

Quantity and delivery destination port or inland depot.

Required regulatory certifications (CSC, TIR, UIC).

Custom modification requirements (electrical wiring, insulation, specialized personnel doors, or custom color coding).

FAQ

Q: What is the exact internal height difference between a Standard and a High Cube container?

A: A High Cube container provides an internal height of 2,698 mm (8'10"), exactly 305 mm (12 inches) higher than a standard dry van container (2,393 mm or 7'10").

Q: What is the standard paint system specification for marine environments?

A: Units destined for marine exposure use a three-tier system: zinc-rich epoxy primer, high-build epoxy intermediate coat, and an aliphatic polyurethane topcoat, achieving a minimum dry film thickness of 160 um conforming to ISO 12944 C5-M corrosivity category.

Q: Are these containers certified for international rail and ocean transport?

A: Yes. Every unit is manufactured in accordance with ISO 668 and ISO 1496-1 and carries an affixed CSC safety approval plate validated by an authorized classification society (ABS, BV, LR, or DNV) for multi-modal transport.

Q: What is the maximum allowable forklift axle load on the wooden floor?

A: The marine-grade plywood floor is engineered to withstand a maximum axle load of 7,260 kg based on a contact patch area of 142 cm2 (30 x 30 cm wheel footprint) per ISO 1496-1 cyclic load testing.

Q: How is condensation prevented during long-term static storage?

A: Units are equipped with four stamped-steel louvered vents featuring internal insect screens, providing passive cross-ventilation to limit internal relative humidity fluctuations. Optional desiccant cargo hooks or active dehumidification packages can be specified upon order.
